LED strips are the most versatile way of adding clean, bright light to any display. Use as many as you want, or as little as you want. Low power-consumption and no need for maintenance makes these strips a popular commodity. (These are rigid strips, not roll type)

  • Highest reliability and Versatile applications
  • Low heat generation
  • Degradation of luminous intensity for entire life span
  • Low power consumption and no maintenance
  • Operates in wide ambient temperature range (-40°F ~ +140°F)
  • Standard color temperature:
    + Warm White: 2700K / 3200K / 3700K / 4200K / 4700K
    + Natural White: 5300K / 6000K / 6500K
    + Cool White: 7500K / 9000K

Series : LED STRIPS | Key Features : UL Recognized E341820 CE Approved

Product Application

  • Retail shop display stands and cases, such as duty-free shops and luxury brand shops
  • Cosmetic/jewelry display shelves and cabinets
  • Light source for wall/ceiling/floor displays
  • Component in variety of interior design fixtures

LED Strip (Solid) - Normal LED (Warm White)

Distance between LEDs 16.67mm
Length/Width of PCB 500mm / 6.0mm
Total # of LEDs 30
Size of LED package 5050
Operating Voltage 12V or 24V
Minimum cut length 50mm for 12V, 100mm for 24V
Color of LED Warm White
Luminous Intensity (Mcd) Typ. 6,500
Luminous Flux (Lm) / LED ~ 20
Color Rendering Index (CRI) 75 ~ 80
Design current (%) 90
Color Temperature (K) 2,400, 2,700 3,200, 3,700 4,200, 4,700
Certification UL Recognized (E341820), CE Approved

LED Strip (Solid) - Normal LED (White)

Distance between LEDs 16.67mm
Length/Width of PCB 500mm / 6.0mm
Total # of LEDs 30
Size of LED package 5050
Operating Voltage 12V or 24V
Minimum cut length 50mm for 12V, 100mm for 24V
Color of LED White
Luminous Intensity (Mcd) Typ. 7,500
Luminous Flux (Lm) / LED ~ 20
Color Rendering Index (CRI) 75 ~ 80
Design current (%) 90
Color Temperature (K) 5,300, 6,500, 7,500, 9,000
Certification UL Recognized (E341820), CE Approved

LED Strip (Solid) - 5630 LED (Warm White)

Distance between LEDs 16.67mm
Length/Width of PCB 500mm / 6.0mm
Total # of LEDs 30
Size of LED package 5630
Operating Voltage 24V only
Minimum cut length 100mm
Color of LED Warm White
Luminous Intensity (Mcd) Typ. 8,500
Luminous Flux (Lm) / LED 20 ~ 22
Color Rendering Index (CRI) 75 ~ 80
Design current (%) 60
Color Temperature (K) 3,000, 3,500, 4,000, 5,000
Certification UL Recognized (E341820), CE Approved

LED Strip (Solid) - 5630 LED (White)

Distance between LEDs 16.67mm
Length/Width of PCB 500mm / 4.5mm
Total # of LEDs 30
Size of LED package 5630
Operating Voltage 12V or 24V
Minimum cut length 50mm for 12V, 100mm for 24V
Color of LED White
Luminous Intensity (Mcd) Typ. 7,500
Luminous Flux (Lm) / LED 20 ~ 22
Color Rendering Index (CRI) 75 ~ 80
Design current (%) 60
Color Temperature (K) 5,300
Certification UL Recognized (E341820), CE Approved

LED Strip (Solid) - Special LED (Dynamic White)

Distance between LEDs 16.67mm
Length/Width of PCB 5005mm / 6.0mm
Total # of LEDs 30
Size of LED package 3528
Operating Voltage 12V or 24V
Minimum cut length 50mm for 12V 100mm for 24V
Color of LED Dynamic White
Luminous Intensity (Mcd) Typ. 7,500
Luminous Flux (Lm) / LED ~ 20
Color Rendering Index (CRI) 75 ~ 80
Design current (%) 95
Color Temperature (K) 2700 ~ 6,500
Certification UL Recognized (E341820), CE Approved

LED Strip (Solid) - RGB LED (common +)

Distance between LEDs 16.67mm
Length/Width of PCB 500mm / 6.0mm
Total # of LEDs 30
Size of LED package 5050
Operating Voltage 12V or 24V
Minimum cut length 50mm for 12V, 100mm for 24V
Color of LED R. G. B
Design current (%) 90
Color Temperature (K) R. G. B.
Certification UL Recognized (E341820), CE Approved

LED Strip (Solid) - Special LED (High Brightness 12.6mm)

Distance between LEDs 12.6mm
Length/Width of PCB 529mm / 6.0mm
Total # of LEDs 42
Size of LED package 5050
Operating Voltage 24V only
Minimum cut length 88.2mm
Color of LED White
Luminous Intensity (Mcd) Typ. 7,500
Luminous Flux (Lm) / LED ~ 20
Color Rendering Index (CRI) 75 ~ 80
Design current (%) 90
Color Temperature (K) 6,500
Certification UL Recognized (E341820), CE Approved

LED Strip (Solid) - Special LED (High Brightness 12.5mm)

Distance between LEDs 12.5mm
Length/Width of PCB 500mm / 6.0mm
Total # of LEDs 40
Size of LED package 5050
Operating Voltage 12V only
Minimum cut length 50mm
Color of LED White
Luminous Intensity (Mcd) Typ. 7,500
Luminous Flux (Lm) / LED ~ 20
Color Rendering Index (CRI) 75 ~ 80
Design current (%) 90
Color Temperature (K) 6,500
Certification UL Recognized (E341820), CE Approved
